GCTC SPECS
MAINSTAGE THEATRE
DIMENSIONS
Distance between tabs: 37’ 3”
Distance between tabs and back wall:26’ 9”
Distance between tabs and furthest US hanging position 21’10”
Painted floor treatment can extended 24” downstage of tabs
Solid set pieces must not extend beyond the DS edge of hard tabs
*Please note that the stage left wall is NOT square to the hard tabs.
LIGHTING
130 X 2.4 kW dimmers (144 total, minus house dimming and reserved, parked dimmers)
Console: ETC ION XE Console with a 20 Fader Wing
Instrument Inventory
* indicates shared inventory with studio theatre
110x Source4 Leko Bodies 575w (HPL575/120)
23x Source4 50 degree tubes
35x Source4 36 degree tubes
4x Source4 36 degree enhanced definition lens tubes
40x Source4 26 degree tubes
26x Source4 19 degree tubes
4x Source4 14 degree tubes
1x Source4 10 degree tube
2 x Source4 5 degree tubes
*12x Source4 Iris kits
18x Colortran 6” Fresnel 750w (BTN)
*9x ETC Source4 Par 575w (c/w lens kits, HPL575w/120)
*9x Colortran 3 cell cyc strips 1000w (FCM)
*6x Elation FUZE z120 Par
*This is a shared inventory with the Studio theatre*
*5x Elation SEVEN batten 42
*This is a shared inventory with the Studio theatre*
*2x iCue mirror (19 or 26 degree lenses only)
*1x City Theatrical DMX iris
*1x Le Maitre G300 fog machine complete DMX control
*1x Le Maitre Radiance Hazer complete DMC control
THEATRE AUDIO
The theatre has a 4x4 I/O Patch bay on the upstage side of each tab. There is an additional audio return patch on each side wall.
The hung PA cannot be moved.
PA:
Yamaha M7CL 32 ch. digital console
Left, Centre, Right 6x Meyer UPJ-1P – Hung on proscenium line
Sides and Rear 4x Meyer UPM-1P – Hung under catwalks
Meyer 600HP Subwoofer – Hung at center
4x QSC HPR 122i Powered stage monitor
2x EV ETX-10P Powered stage monitor
Playback:
Mac mini or Apple M1 Macbook Pro depending on needs of the production
Qlab 4 licence (full licence)
Focusrite Scarlett 18i20 USB interface
Recording/Editing:
Protools
Focusrite Scarlett 18i20 USB interface (Note- this is independent of the Playback focusrite)
Recording and editing is generally done on an Apple M1 Macbook Pro
Microphones/accessories:
*This is a shared inventory with Studio Theatre; please contact TD to confirm availability*
4x Shure Beta 58A
2x Shure 57
1x Shure Beta 52A
4x Sennheiser E604
3x Sennheiser MD421 II
4x Sennheiser E914
2x AKG C414 B-XL2
2x Nuemann KM184
4x JDI Radial Passive DI
4x Yorkville DI
1x Wireless kit with 4 Shure SLXD4 receivers in 6U case
2x SLXD bodypack with WL184 Lavalier microphone
4x SLXD2/SM58 handheld microphones
8x Tall mic stand
4x short mic stand
2x straight mic stand
Clear Com
1x matrix base station
2x wireless belt packs
4x wired belt packs (2 reserved for lx and snd operators)
Soft goods (goods are 19' high)
4x 4’ legs (black)
6x 8’ legs (black)
6x 6’ legs (black)
1x 40’ black backdrop
1x 40’ black scrim
1x 40’ cyclorama
1x 6’ high x 40’ wide border
1x 4’ high x 40’ wide border – Generally this is hung on the proscenium line
Video and projections
Please note that GCTC does not have a dedicated video/projection department.
*This is a shared inventory with Studio Theatre; please contact TD to confirm availability*
Recording
1x Canon HF G50
1x Canon XA40 with media handle
1x Vixia HF R52
2x GoPro Hero 7 with media mod
1x Sennheiser MKE200
1x Sennheiser MKE400
1x Sennheiser MKE440
Streaming
1x Atem mini iso pro stream controller
1x ACER Nitro 5 notebook w 15.6” screen and AMD Ryzen 7 graphics card, 16GB DDR4 ram
2x El gato camlink HDMI-USB adaptors
Projections
2x Panasonic PT-DW800 projector
1x Panasonic PT-EX500 projector
3x ET-DLE 150 zoom lens
2x ET-DLE 055 fixed lens
1x 2020 Macbook Pro with M1 chip
1x USB-C dock *This allows up to 2 external screens/projectors
